Beer Regulator - Type 30 - MK4 - Co2 Regulator - Dual Gauge

The MK4 regulator provides reliable gas control. It has a large body with high flow rates and has a precision diaphragm allowing accurate adjustments with the easy to use adjustment knob.

Gas Line:
Select your a gas line and disconnect for this regulator here:

New and improved features:

  • Steel Gauges made from thicker steel
  • Gauges read in kPa, Bar and PSI
  • New Colour Coded pressure release valves (PRV) allowing different pressure levels for safety.
  • M6 Mounting Holes for mounting options.
  • 0-50 PSI recommended working pressure (higher pressure gauges and PRV can be fitted to make this model go up to 100 PSI)
  • Green (65psi) PRV installed by default. Lower (35psi) and higher (100psi ) pressure relief valves are available (sold separately).
  • 1/4" MFL threaded outlet (uses same swivel nut & barb as MFL ball lock disconnects & also fits our MFL 8mm push fittings)
  • Comes with 8mm Push Fitting by default. or will take any 1/4" FFL flare female threaded adapter
  • Default to work with CO2 but can also be used with: Nitrogen, Oxygen, Argon & Helium by changing the cylinder connection (stem) to the needed fitting. - Stem & nut sold separately.

This regulator has been designed so that the whole seat and seat cap assembly are manufactured as a fully encapsulated part. This adds to the reliability and in the case that the regulator is eventually opened up for servicing it reduces the chance of this assembly becoming contaminated by the service agent. This further improves reliability.

Output Pressure Gauge: 0-100 PSI
Tank Pressure Gauge: 0-3000 PSI
Outlet: MFL with Barbed Swivel Nut
Effective Working Pressure: 0-50 PSI

Controls high pressure CO2 from a cylinder down to pressures usable in a beer keg or other situations where low pressure is needed.

This is the most common type of regulator used in homebrew setups with 19L corny kegs or commercial keg setups. It will fit onto any standard NZ spec co2 cylinder (type 30 valve).

We also have sodastream adapters for these regulators so you can use a sodastream cylinder with with to have a more portable solution.

Feel free to send us a message if you have any questions or specific kegging / brewing needs.


Ask a Question


Ask a Question
  • Hi! I have a sealing machine for meals (nothing related to beer) and I need I gas regulator for a cylinder that is co2 and nitrogen mixed. Do you think this regulator would work for that? Thanks, Aimee

    Hi Aimee -
    Thanks for the message.  For that kind of cylinder you would a type 50 regulator (different fitting). We have them here:

    There are however a very few N2/co2 mix cylinders that will take a Type30 regulator but it is quite rare - If you already have the cylunder yoiu can take an image of the valve thread and we can confirm if you like.
    Cheers - Andrew.

  • Hello, I have a type 50 connector for use with 80/20 nitrogen mix but there is no washer inside the connector. Shouldn't there be one? Teflon ? Rubber? Cheers

    Hi Dean -
    With a nitrogen stem there is no washer/gasket - it is a metal on metal connection.  It needs to be done up nice and tight as its higher pressure than Co2.
    You can see the stem we use here:

  • What’s the difference between this regulator and the other one at the same price? Can I connect a 1/4” line to this or do I need extra fittings?

    Hi Kevin,
    Not much difference. This has an MFL threaded outlet so has the option of a few different fittings. It comes with a screw on 6mm barb. So if your line is 5mm inner diameter then All good. Or put a screw on fitting with female pushfit outlet to fit your hose.  Cheers.
